■產品結構原理　　HR系列臥式雙級活塞推料離心機主要由泵組合、推料機構、機座、軸承組合、轉鼓、篩網、機殼及電控箱等零部件組成。推料機構、轉鼓、篩網等零部件通過軸承組合支承在機座上。泵組合亦由基座支承，其油泵伸入油池內。油路中裝有油冷卻器。回轉體通過三角膠帶與主機皮帶輪連接。電控箱系一單獨系統，安裝在與主機相適宜的位置。　　主機全速運轉后，懸浮液通過進料管進入裝在內轉鼓上的分配盤，在離心力的作用下，懸浮液均勻的分布在內轉鼓的板網上，液相經板網網隙和轉鼓濾孔而瀉出，而固相則被截留在板網上形成環狀濾渣層。由于內轉鼓的往復運動，將濾渣沿轉鼓軸向向前推移，經外轉鼓前的集料槽卸出。■ProductstructureprincipleHrserieshorizontaldoublepistonpushcentrifugeismainlycomposedofpumpcombination,pushinstitution,frame,bearingcombination,drum,screenmesh,chassisandelectriccabinetandothercomponents.Pushingmechanism,drum,screenmeshandothercomponentsbycombinationofbearingsupportonthestand.Alsobythepedestalbearingpumpcombination,theoilpumpintooilpool.Areinstalledinthehydraulicoilcooler.Planethroughthetriangletapetoconnecttohostpulley.Electriccabinetisaseparatesystem,installedinthesuitablehostposition.Throughthefeedingtubeintothehostafterrunningatfullspeed,suspensioninstalledonthedrum,thedistributionoftheplate,undertheactionofcentrifugalforce,thesuspensionofuniformdistributionofdrumplateonline,liquidphaseaftertheplatenetclearanceanddrumfilterholeandeffusion,whilethesolidphasetrappedonboardacircularcakelayeronthenet.Duetodantianthereciprocatingmovementofthedrum,theresiduealongthedrumaxialgoesforward,theouterdrumaggregateslotbeforedischarge.■產品特點與用途?　　HR系列離心機為臥式雙級活塞推料連續操作的過濾式離心機。他在全速下完成所有的操作工序，如進料、分離、洗滌、干燥和卸料等。適用于含中顆粒的結晶狀或短纖維狀的濃懸浮液的分離(晶狀物粒子尺寸0.1-10mm、短纖維30mm以內)，廣泛用于化工、化肥、制鹽、制藥、食品、輕工等工業部門。　　HR系列離心機具有自動連續操作、連續排渣、生產能力高、對晶粒不易破碎、濾渣可洗滌等傳統優點外，還具有高濾渣生產量、高固體回收率、低濾渣含濕量、低能量消耗等特點。　　應用物料范例：氯化鈉、硫酸鈉、硝酸鈉、硫酸鋅、重絡酸鈉、硫酸銨、硼酸、醋酸纖維、硝化纖維、尿素、氯化鉀、硫酸鉀、碳酸鉀、磷酸鹽、七水硫酸亞鐵、丙烯酰胺、小蘇打、硝化纖維、磷酸一銨、氯化銨、草酸、煙氣硫胺、元明粉等。■ProductcharacteristicsandUSES?　　HRseriescentrifugeishorizontaldoublepistonpushingcontinuousoperationoffilteringcentrifuge.Hedoneatfullspeedalltheoperationprocess,suchasfeeding,separating,washing,dryinganddischarging,etc.Suitableforcontainingthecrystallizationofparticlesintheseparationofconcentratedsuspensionorshortfibrous(crystalmaterialparticlesize0.1-10mm,shortfiberswithin30mm),widelyusedinchemical,chemicalfertilizer,salt,pharmaceutical,food,lightindustryandotherindustries.　　HRseriescentrifugewithautomaticcontinuousoperation,continuousdischarge,highproductioncapacity,thegrainsizeisnoteasytobreakage,residueinthetraditionaladvantagessuchaswashing,butalsohashighresidueinproduction,highsolidrecovery,lowresidueinmoisturecontent,lowenergyconsumption,etc.　　Applicationmaterialexamples:sodiumchloride,sodiumsulfate,sodiumnitrate,zincsulfate,sodiumheavycomplexacid,ammoniumsulfate,boricacid,celluloseacetate,cellulosenitrate,urea,potassiumchloride,potassiumsulfate,potassiumcarbonate,phosphate,sevenwaterferroussulfate,acrylamide,sodiumbicarbonate,nitrocellulose,monoammoniumphosphate,ammoniumchloride,oxalicacid,fluegassulfuramine,sodiumsulphate,etc.■工作原理workingprinciple■結構示意圖structurediagram■主要技術參數MainParameter■特別提示　　1、技術參數以產品說明書為準。　　2、洽詢時，請顧客詳細賜告物料特性參數及工況條件要求。　　3、根據顧客的特殊需要，我們可以采取個性化的設計與制造：　　(1)材質：物料接觸部分材質可為304、316L、2205、2507、904L、TA2等。　　(2)電機型式：可采用普通型或防爆型電機等。　　(3)排液方式：母液與滌液可采取混合排放或分流排放。　　(4)濾網間隙寬度選擇范圍：0.08-0.40mm。　　(5)HR500、HR630、HR800、HR1000可采用螺旋輸送器進干料進行二次脫水。(6)可商定其他技術要求。■Specialnote?　　1,thetechnicalparametersoftheproductspecificationshallprevail.　　2,inquire,pleasecustomerdetailsgiventothematerialcharacteristicparametersandworkingconditionrequirements.　　3,accordingtothespecialneedsofcustomers,wecantakethepersonalizeddesignandmanufacturing:

型號：
HS530
HS500

■產品結構原理　　HR系列臥式雙級活塞推料離心機主要由泵組合、推料機構、機座、軸承組合、轉鼓、篩網、機殼及電控箱等零部件組成。推料機構、轉鼓、篩網等零部件通過軸承組合支承在機座上。泵組合亦由基座支承，其油泵伸入油池內。油路中裝有油冷卻器。回轉體通過三角膠帶與主機皮帶輪連接。電控箱系一單獨系統，安裝在與主機相適宜的位置。　　主機全速運轉后，懸浮液通過進料管進入裝在內轉鼓上的分配盤，在離心力的作用下，懸浮液均勻的分布在內轉鼓的板網上，液相經板網網隙和轉鼓濾孔而瀉出，而固相則被截留在板網上形成環狀濾渣層。由于內轉鼓的往復運動，將濾渣沿轉鼓軸向向前推移，經外轉鼓前的集料槽卸出。■ProductstructureprincipleHrserieshorizontaldoublepistonpushcentrifugeismainlycomposedofpumpcombination,pushinstitution,frame,bearingcombination,drum,screenmesh,chassisandelectriccabinetandothercomponents.Pushingmechanism,drum,screenmeshandothercomponentsbycombinationofbearingsupportonthestand.Alsobythepedestalbearingpumpcombination,theoilpumpintooilpool.Areinstalledinthehydraulicoilcooler.Planethroughthetriangletapetoconnecttohostpulley.Electriccabinetisaseparatesystem,installedinthesuitablehostposition.Throughthefeedingtubeintothehostafterrunningatfullspeed,suspensioninstalledonthedrum,thedistributionoftheplate,undertheactionofcentrifugalforce,thesuspensionofuniformdistributionofdrumplateonline,liquidphaseaftertheplatenetclearanceanddrumfilterholeandeffusion,whilethesolidphasetrappedonboardacircularcakelayeronthenet.Duetodantianthereciprocatingmovementofthedrum,theresiduealongthedrumaxialgoesforward,theouterdrumaggregateslotbeforedischarge.■產品特點與用途?　　HR系列離心機為臥式雙級活塞推料連續操作的過濾式離心機。他在全速下完成所有的操作工序，如進料、分離、洗滌、干燥和卸料等。適用于含中顆粒的結晶狀或短纖維狀的濃懸浮液的分離(晶狀物粒子尺寸0.1-10mm、短纖維30mm以內)，廣泛用于化工、化肥、制鹽、制藥、食品、輕工等工業部門。　　HR系列離心機具有自動連續操作、連續排渣、生產能力高、對晶粒不易破碎、濾渣可洗滌等傳統優點外，還具有高濾渣生產量、高固體回收率、低濾渣含濕量、低能量消耗等特點。　　應用物料范例：氯化鈉、硫酸鈉、硝酸鈉、硫酸鋅、重絡酸鈉、硫酸銨、硼酸、醋酸纖維、硝化纖維、尿素、氯化鉀、硫酸鉀、碳酸鉀、磷酸鹽、七水硫酸亞鐵、丙烯酰胺、小蘇打、硝化纖維、磷酸一銨、氯化銨、草酸、煙氣硫胺、元明粉等。■ProductcharacteristicsandUSES?　　HRseriescentrifugeishorizontaldoublepistonpushingcontinuousoperationoffilteringcentrifuge.Hedoneatfullspeedalltheoperationprocess,suchasfeeding,separating,washing,dryinganddischarging,etc.Suitableforcontainingthecrystallizationofparticlesintheseparationofconcentratedsuspensionorshortfibrous(crystalmaterialparticlesize0.1-10mm,shortfiberswithin30mm),widelyusedinchemical,chemicalfertilizer,salt,pharmaceutical,food,lightindustryandotherindustries.　　HRseriescentrifugewithautomaticcontinuousoperation,continuousdischarge,highproductioncapacity,thegrainsizeisnoteasytobreakage,residueinthetraditionaladvantagessuchaswashing,butalsohashighresidueinproduction,highsolidrecovery,lowresidueinmoisturecontent,lowenergyconsumption,etc.　　Applicationmaterialexamples:sodiumchloride,sodiumsulfate,sodiumnitrate,zincsulfate,sodiumheavycomplexacid,ammoniumsulfate,boricacid,celluloseacetate,cellulosenitrate,urea,potassiumchloride,potassiumsulfate,potassiumcarbonate,phosphate,sevenwaterferroussulfate,acrylamide,sodiumbicarbonate,nitrocellulose,monoammoniumphosphate,ammoniumchloride,oxalicacid,fluegassulfuramine,sodiumsulphate,etc.■工作原理workingprinciple■結構示意圖structurediagram■主要技術參數MainParameter■特別提示　　1、技術參數以產品說明書為準。　　2、洽詢時，請顧客詳細賜告物料特性參數及工況條件要求。　　3、根據顧客的特殊需要，我們可以采取個性化的設計與制造：　　(1)材質：物料接觸部分材質可為304、316L、2205、2507、904L、TA2等。　　(2)電機型式：可采用普通型或防爆型電機等。　　(3)排液方式：母液與滌液可采取混合排放或分流排放。　　(4)濾網間隙寬度選擇范圍：0.08-0.40mm。　　(5)HR500、HR630、HR800、HR1000可采用螺旋輸送器進干料進行二次脫水。(6)可商定其他技術要求。■Specialnote?　　1,thetechnicalparametersoftheproductspecificationshallprevail.　　2,inquire,pleasecustomerdetailsgiventothematerialcharacteristicparametersandworkingconditionrequirements.　　3,accordingtothespecialneedsofcustomers,wecantakethepersonalizeddesignandmanufacturing:

■產品結構原理　　結構：GK臥式刮刀卸料離心機主要由刮刀機構、門蓋組件、轉鼓組件、機座組件、傳動系統、液壓系統及電氣控制系統等部件組成。機座組件為承載部件，主要包括底板、機殼;軸承箱及背板為整體焊接件;轉鼓組件為轉動部件，主要由轉鼓、主軸、軸承及從動皮帶輪組成，其中轉鼓通過主軸懸臂支承于機座內;機殼前端為門蓋，門蓋上裝有刮刀機構、進料管、洗滌管及卸料斗;液壓系統單獨外置;主電機上裝有液力偶合器，通過三角帶與從動皮帶輪相聯;電氣控制系統為單獨部件，可安裝在操作適宜的位置。　　工作原理：主機全速運轉后，打開進料閥，被分離的懸浮液通過布料斗進入轉鼓內并均勻地分布在過濾介質上。在離心力作用下，液相通過過濾介質和轉鼓壁上的小孔甩出轉鼓體外，而固相則截留在過濾介質上形成濾渣。當濾渣層達到一定厚度時，關閉進料閥，同時打開洗滌閥對固相物進行洗滌后甩干。最后利用旋轉刮刀將濾渣層卸下并經卸料斗送出機外。■ScopeofapplicationStructure:GKhorizontalscraperdischargecentrifugeismainlycomposedofscrapermechanism,doorcovercomponents,drumassembly,framecomponents,transmissionsystem,hydraulicsystemandelectriccontrolsystemandotherparts.Framecomponentforbearingparts,mainlyincludingbackplane,casing;BearingboxandthebackforthewholeproductDrumcomponentsforrotatingparts,mainlybytherotarydrum,mainshaft,bearingandthedrivenpulley,therotarydrumthroughthespindlecantileversupportwithintheframe;Chassisfrontgateofthedoorcover,coverisequippedwithscrapermechanism,feedpipe,washinganddischargehopper;Separateexternalhydraulicsystem;Onthemainmotorisequippedwithhydrauliccoupling,throughtriangleiscombinedwiththedrivenpulley;Electricalcontrolsystemforsingleparts,canbeinstalledinthelocationoftheappropriateoperation.Workingprinciple:thehostafterrunningatfullspeed,openthefeedvalve,isolatedslurrythroughclothbucketintothedrumandevenlydistributedonthefiltermedium.Undertheeffectofcentrifugalforce,theliquidthroughafiltermediumandflungoutdrumdrumwallholesinvitro,whilethesolidphaseinterceptformafiltercakeonthefiltermedium.Whenthefiltercakelayerreachesacertainthickness,feedvalveshut,openatthesametimewashingvalveofthesolidphaseafterthewashingtodry.Therotatingscraperisusedtochangethefilterresiduelayertounloadandclosedtothedischargehoppersent.■產品特點與用途　　GK系列離心機是一種臥式寬刮刀卸料、自動控制、連續循環工作過濾離心機。能在全速運轉下循環實現進料、分離、洗滌、脫水、卸料、洗網等工序。具有結構新穎、運轉平穩、操作方便、適用范圍大、自動化程度高、勞動強度低等特點。適合分離含固相物粒度大于0.015mm,濃度范圍在25-60%的懸浮液。防爆型可用于易燃易爆的固液分離。適用于化工、化肥、食品、制藥等行業。GKseriescentrifugeisakindofhorizontalscraperdischargewide,automaticcontrol,continuousloopfilteringcentrifuge.Canberunatfullspeedloopachievefeeding,separating,washing,dehydration,unloadingandwashthenet.Hastheadvantagesofnovelstructure,stablerunning,easyoperation,largescope,highdegreeofautomation,lowlaborintensity,etc.Suitableforseparationofsolidphaseparticlesizegreaterthan0.015mm,concentrationrangein25-60%ofthesuspension.Explosion-prooftypecanbeusedininflammableandexplosivesolid-liquidseparation.Suitableforchemical,fertilizer,food,pharmaceuticalandotherindustries.?■主要技術參數Themaintechnicalparameters■結構示意圖Structurediagram■特別提示　　1、技術參數以產品說明書為準。　　2、洽詢時，請顧客詳細賜告物料特性參數及工況條件要求。　　3、根據顧客的特殊需要，我們可以采取個性化的設計與制造：　　(1)材質：物料接觸部分材質可為304、316L、2205、2507、904L、TA2等(也可采用襯包結構)。　　(2)電機型式：可采用普通型或防爆型電機等。　　(3)排液方式：母液與滌液可采取混合排放或分流排放。　　(4)GK1600-NB可采用螺旋卸料結構。　　(5)可商定其他技術要求。■Specialnote1,thetechnicalparametersoftheproductspecificationshallprevail.2,inquire,pleasecustomerdetailsgiventothematerialcharacteristicparametersandworkingconditionrequirements.3,accordingtothespecialneedsofcustomers,wecantakethepersonalizeddesignandmanufacturing:(1)material:materialcontactpartofthematerialfor304,316l,2205,2507,904l,TA2(alsocanuselinepackagestructure).(2)motortype:canuseordinaryorexplosion-proofmotor,etc.(3)drainageway:motherliquorblendedwithpolyesterliquidcanadoptemissionsorbypassemissions.(4)GK1600-NBcanadoptspiraldischargingstructure.(5)canbeagreedothertechnicalrequirements.

■產品結構原理　　PGZ系列平板離心機是一種全自動控制的立式刮刀卸料離心機，在電氣控制下，轉鼓啟動達到進料速度后，控制系統打開進料閥，被處理懸浮液從進料管入轉鼓。在轉鼓高速旋轉產生的強大離心力作用下，進入轉鼓內的懸浮液被均布于轉鼓內壁的過濾介質上，成空心圓柱狀。液相通過過濾介質和轉鼓上的許多小孔被甩出鼓外。由機殼內壁和底盤搜集，從出液管排出，而固相粒子則被留在過濾介質上。當進料量達到設定值。由料層控制器(或進料時間)向控制系統發出信號，關閉進料閥門。同時，根據工藝需要可對物料進行洗滌，洗滌達到要求后，在脫水速度下進行二次脫水。處理物料達到分離要求，控制系統控制主電機將回轉體的轉速降到卸料速度，卸料機構采用窄刮刀，先由旋轉缸驅動徑向刮料，到位后停留一下，再軸向行程卸料，下降到位刮下轉鼓壁上的物料。固體顆粒通過刮刀卸料借助重力。經轉鼓底的卸料口從機座底部排出。機器完成一個工作循環，在控制系統(PLC)的控制下進入到下一個工作循環。■Scopeofapplication　　PGZseriesplatecentrifugeisakindofautomaticcontrolofverticalscraperdischargecentrifuge,undertheelectricalcontrol,drumstartedafterreachingfeedspeed,openthefeedvalvecontrolsystem,treatedsuspensionfromafeedingtubeintothedrum.Inthedrumundertheeffectsofthestrongcentrifugalforceathighspeed,intothedruminsuspensionwerealldrumontheinnersurfaceofthefiltermedium,andintothehollowcylindrical.Liquidthroughthefiltermediumandthemanyholeswasthrownonthedrum.Collectionbychassisandcasingwall,fromthedischargepipeofproducedliquid,andsolidphaseparticlesareonthefiltermedium.Whenthefeedratetoachievethesetvalue.Bymateriallayercontroller(orfeed)signaltothecontrolsystem,closetheinletvalve.Atthesametime,accordingtoprocessneedswashingforthematerial,afterwashinguptopar,secondarydewateringunderthedehydrationrate.Processingmaterialsmeettherequirementsofseparation,thecontrolsystemtocontrolthemainmotortoreducethespeedofsolidofrevolutiontounloadingspeed,usinganarrowbladeindischargingscraperdrivenbyrotarycylinderradialfirst,stayinplaceafteramoment,andaxialdischarge,declineinplaceunderthescrapingdrumwallmaterial.Solidparticlesbyscraperdischargewiththehelpofgravity.Thedrumbottomdischargeoutletfromthebottomofthestandout.Machinetocompleteaworkcycle,underthecontrolofthecontrolsystem(PLC)tothenextworkcycle.■產品特點與用途　　PGZ系列平板式離心機為間隙式周期性工作方式的離心機。它在可編程序的控制下，由電氣系統自動完成工作周期，可實現多次進料、多次洗滌、多次脫水的要求。采用了變頻調速電機，機器各階段轉速可根據需要進行任意調節。其工序和時間可通過調整程序而隨意調整，工作程序分為七個工序：1.轉鼓啟動;2.進料;3.脫液;4.洗滌;5.二次脫液;6.轉鼓制動至低速;7.卸料，以達到最佳工作效率。PGZseriesplatetypecentrifugecentrifugeworkingforintermittentcyclicalmanner.Itunderthecontroloftheprogrammable,finishtheworkbyelectricalsystemautomaticcycle,whichcanrealizetherequirementoffeeding,washing,dehydrationmanytimesmanytimes.Adoptedthevariablefrequencyspeedregulatingmotor,indifferentstagesofthemachinespeedcanbeadjustedaccordingtoneed.Theprocessandthetimecanbeadjustedfreelybyadjustingtheprocess,andtheworkingprocedureisdividedintosevenprocess:1.Thedrumtostart;2.Incomingmaterial;3.Totakeofftheliquid;4.Washing;5.Thesecondaryfluid;6.Drumbraketoslow;7.Discharge,inordertoachievethebestworkingefficiency.■工作流程Theworkingprocess■主要技術參數Themaintechnicalparameters■特別提示　　1、技術參數以產品說明書為準。　　2、洽詢時，請顧客詳細賜告物料特性參數及工況條件要求。　　3、根據顧客的特殊需要，我們可以采取個性化的設計與制造：　　(1)材質：物料接觸部分材質可為304、316L、2205、2507、　　904L、TA2等。　　(2)驅動方式：普通型或防爆型單速電機等。　　(3)揭蓋方式：油缸、汽缸、電動缸或機械平衡器等。　　(4)電控方式：半自動、全自動或PLG程序控制等。　　(5)可商家其他技術要求。■Specialnote1,thetechnicalparametersoftheproductspecificationshallprevail.2,inquire,pleasecustomerdetailsgiventothematerialcharacteristicparametersandworkingconditionrequirements.3,accordingtothespecialneedsofcustomers,wecantakethepersonalizeddesignandmanufacturing:(1)material:materialcontactpartofthematerialfor304,316l,316,2507,904l,TA2,etc.(2)drivemode:normalorexplosion-prooftypesinglespeedmotor,etc.(3)peelway:oilcylinder,cylinder,electriccylinderormechanicalbalance,etc.(4)electriccontrolmethods:semi-automatic,fullyautomaticorPLGprocesscontrol,etc.(5)businessothertechnicalrequirements.
